317C10-IPC Daha büyük görüntüle

317C10-IPC

Yeni ürün

  • H.264 video formatı,
  • G711U ses sıkıştırması
  • 1920x1080, 25fps
  • 10/100 RJ45
  • HTTP,TCP/IP,ICMP.RTSP,RTP,UDP,RTCP,SMTP,DHCP,DNS,
  • PPPoE desteği
  • ONVIF,POE
  • -20℃~+55℃

Daha fazla bilgi

Daha fazla bilgi

Model

TS-317C10-IP

Model name

Metal side-looking IPC

Image sensor

COLOR  1/4"CMOS

Resolution

PAL/ NTSC:1280(H)×720(V)

Horizontal Resolution

Color 720P( Black720P)

Min.illumination

Color 0. 1Lux @(F1.2,AGC ON),0 LUX with IRBlack 0.01 Lux@

(F1.2,AGC ON),0 LUX with IR

Signal system and Frames

PAL(25FPS)/NTSC(30 FPS) Optional

Video compression

H.264/MJPEG

shutter speed

Auto expose,1/50S to 1/100000S

Lens

3MP HD 2.8mm

FOV

Horizontal:0°~60°; Vertical:0°~60°;Rotation:0°~355°

Day and night mode

Dual ICR auto color/night

synchronization system

Inter-sync

Video output

1CH,meet ONVIF protocol

(Connector: RJ45 and 6pins aviation optional)

Video compressed output rates

32 Kbps~8Mbps

SN

>52db

Mount protocol

RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP/ONVIF

Audio

can not built in

Color

Black

Operating temperature and humidty

Temperature:-10℃~60℃, humidity: <90%(no condensation)

Power supply

DC12V±10%

Power consumption

<4W

Videooutput cable length

40cm

Ingress protection

 Waterproof IP65,IP66 customizable

IR range

10 Meters

Selection Guide

A:SONY  CCD   B:SHARP  CDD     C:CMOS

 Resulation

10:720P   11:960P   12:1080P

Dimensions(mm)

Product dimension:Length89mm*Width77mm*Height63mm,Package dimension: 133x83x75mm

Net/gross

291 g /338g
