> >>RB912UAG-2HPnD
RB912UAG-2HPnD Daha büyük görüntüle

RB912UAG-2HPnD

Yeni ürün

RB912UAG-2HPnD çok yönlü bir cihazdır.
Entegre 2.4GHz yüksek güçlü
kablosuz karta ve 802.11 kablosuz veya
3G kartı için ek miniPCIe yuvasına sahip
küçük bir kablosuz yönlendirici.
Gigabit portu 802.11n kablosuz hızların
tüm potansiyelini kullanmaya yardımcı olur.

Daha fazla bilgi

Daha fazla bilgi

Details
Product codeRB912UAG-2HPnD
CPU nominal frequency600 MHz
CPU core count1
ArchitectureMIPS-BE
Size of RAM64 MB
10/100/1000 Ethernet ports1
MiniPCI-e slots1
Wireless standards802.11b/g/n
Wireless chip modelAR9342
Number of USB ports1
Power Jack1
Supported input voltage8 V - 30 V
PoE inYes
Voltage MonitorYes
PCB temperature monitorYes
Dimensions105x105mm
Operating SystemRouterOS
Tested ambient temperature-40°C .. +70°C tested
License level4
CPUAR9342
USB slot typeUSB type A
Number of chains2
Storage typeNAND
Storage size128 MB
Suggested price$79.00

Wireless specifications

2.4 GHz
Transmit power (dBm)Receive SensitivityTransmit power (mW)
1MBit/s30-1001000
11MBit/s30-941000
6MBit/s30-961000
54MBit/s27-78501
MCS030-961000
MCS724-73251

wireless parameters may be limited in software, depending on your local regulatory limitations

Ethernet test results

RB912UAG-2HPnDAR9342 1G 1 port test
ModeConfiguration1518 byte512 byte64 byte
kppsMbpskppsMbpskppsMbps
Bridgingnone (fast path)81.0983.7232.0950.3269.6138.0
Bridging25 bridge filter rules81.0983.786.0352.387.644.9
Routingnone (fast path)81.0983.7210.0860.2226.9116.2
Routing25 simple queues81.0983.7103.9425.6106.654.6
Routing25 ip filter rules56.8689.859.6244.160.531.0
  1. All tests are done with Xena Networks specialized test equipment(XenaBay),and done according to RFC2544 (Xena2544)
  2. Max throughput is determined with 30+ second attempts with 0,1% packet loss tolerance in 64, 512, 1518 byte packet sizes
  3. Values in Italic indicate that max throughput was reached without maxing out CPU, but because board interface configuration was maxed out
  4. Test results show device maximum performance, and are reached using mentioned hardware and software configuration, different configurations most likely will result in lower results

NOT: Kaynak (Routerboard.com)
